Spraying nozzle diagram |
|||||
|
|
 |
||||
|
1 |
Threaded nozzle body-hose D. 20 F7 |
1 |
0,5 bar check valve capsule |
||
|
1 |
Threaded nozzle body-hose 1/2" F7 |
053.0904.02 | 2 |
1/2"
threaded, hinged nozzle body F.7 |
|
|
1 |
Threaded nozzle body-hose 3/4" F10 | 2 |
3/4" F.1O threaded hinged clamp type nozzle body |
||
|
1x |
Quick fitting nozzle body-hose D.20 F7 | 2x | 1/2" F.7 quick fitting hinged clamp type nozzle body | ||
|
1x |
Quick fitting nozzle body-hose 1/2" F7 F7 | 2x | 3/4" F.10 quick fitting hinged nozzle body | ||
|
1x |
Quick fitting nozzle body-hose 3/4" D.10 | 3 | 3/4" fly nut | ||
|
*2 |
Screw | 4 | EPDM check valve diaphram | ||
|
3 |
20 mm hinged clamp type nozzle | 5 | Insert | ||
|
3 |
1/2" hinged clamp type nozzle | 6 | O Ring for nozzle 7 D. hole 6x2,5 | ||
|
3 |
3/4" hinged clamp type nozzle | 6 | O Ring for nozzle 10 D. hole 9,1 x2,6 | ||
|
4 |
O Ring for nozzle 7 D. hole 6x2,5 | *7 | Stainless steel self-tapping screw Ø 4,8x15,9 | ||
|
4 |
O Ring for nozzle 10 D. hole 9,1x2,6 | 8 | 20 mm D. hinged clamp | ||
|
5 |
3/8" fly nut | 8 | 1/2" D. hinged clamp | ||
|
6 |
Insert | 8 | 3/4" D. hinged clamp | ||
